Steam Tube Bundle Dryer

Jiangsu Stord Works Co., Ltd. is one of the most professional steam tube bundle dryer manufacturers and suppliers in China. If you're going to wholesale steam tube bundle dryer at competitive price, welcome to get quotation from our factory. Customized orders are welcome.

Product description

Steam tube bundle dryer takes advantage of internal high-temperature tube bundles which rotate slowly inside to reach moisture evaporation aim. Steam enters tube through rotary joint. After heat exchanging heat, steam will become condensed water and be discharged out. Moisture in raw materials will become steam outside tube owing to heat and be discharged out by dehumidification fan. Raw materials are scooped up by rotary shovel and form material curtain. Materials will uniformly fall on external surface of heating tube. Shovels are distributed in spiral line. While efficiently exchanging heat, raw materials will be driven forward to discharging outlet. Finally, dried materials will be discharged out.

Feature

1.     Shaft adopts integrated processing structured: rotor spindle is processed by large-scale boring lathe to make sure concentricity, guarantee stable running process and expand service life.

2.     Self-aligning sliding in conjunction with bearing design: one end adopts SKF self-aligning bearing and the other end adopts special designed bearing, which makes whole system smoother.

3.     Automatic lubrication system: equipped with no-oil alarming system in order to protect bearing.

4.     Tube bundle adopts superior texture and special processing craft. Tube bundle adopts superior boil steel and expanding process for firm connection.

Advantage

1.     Low heat and electricity consumption; it only needs 1.2 to 1.4 ton steam for evaporating one-ton moisture.

2.     Wide application range: large evaporation capacity; can also be used to dry high moisture raw materials.

3.     Strong technical and R&D team: customize according to customers’ specific demands. Different combination among shovel plate, pushing plate and discharging plate can be used to deal with various raw materials. We will assist customer to reach best drying curve and best drying effect.

4.     Combination between damper plate and returning device: reach to highest heat exchanging efficiency in shortest retention time.

5.     Wide adaptability of drying parameters (drying time can be adjusted according to different materials’ requirements), high automation level; can work both continuously and discontinuously in order to adapt to utilization crafts.

6.     Raw materials are dried under closed inner chamber in negative pressure state; clean work environment, pollution free and low noise. Owing to less auxiliary machines, this steam tube bundle dryer occupies less area.
