Rotary Steam Tube Bundle Dryer

Jiangsu Stord Works Co., Ltd. is one of the most professional rotary steam tube bundle dryer manufacturers and suppliers in China. If you're going to wholesale rotary steam tube bundle dryer at competitive price, welcome to get quotation from our factory. Customized orders are welcome.

Product description

We provide the Tube Bundle Rotary Dryer. In this dryer, tube bundle is rotating inside a stationary housing. Heating Media is passed through the tubes of Tube Bundle. Material to be dried is fed into the stationary dryer housing at a suitable location at one end. The material gets lifted up showered on tubes with help of specially designed lifters provided on tube bundle periphery. The material gets dried by conduction heat transfer discharged from the other end. AVM offers customized configurations of Tube Bundle Dryers.

Working principle

1. heat source pass through the sealed jacket.

2. the heat will be transmitted to the raw material to be dried through inner shell.

3. under driving of power, the tank is rotated slowly and the raw material inside it is mixed continuously. then the purpose of reinforced drying can realized.

4. the material is at a vacuum state, the drop of steam jpressure makes the moisture at the surface of raw material become saturation and will evaporate.

5. the solvent will be discharged through vacuum pump.

6. the inner moisture of raw material will infiltrate, evaporate and discharge continuously. these three processes are carried continuously and the purpose of drying can be realized within a short time.

Features

1.The dryer has strong anti-overload ability, large processing capacity, low fuel consumption and low drying cost.

2. The new feeding and discharging device eliminates the feeding blockage, discontinuity, non-uniformity and material return of the drum dryer, and reduces the load of the dust removal system.

3. The dryer achieves "zero-level thrust", which greatly reduces the wear of the back-up wheel, and the barrel runs smoothly and reliably.

4. The moisture of the product can be controlled according to user's requirements.
